EQUIPMENT LIST EQUIPMENT LIST We have over 20 CNC machines, including five 5 Axis machines. Out of five 5 Axis machines, we have two 5 Axis Mill-Turn machines.
2024 Mazak Variaxis C-600 5-Axis Spindle: 20,000 RPM 57HP Work envelope: ø28.74’’x17.72’’
2024 Brother U500XD1-5 Axis Spindle Speed: 16,000 RPM Fastest 5 axis machine available on the market.
2024 Brother M300XD1-5 Axis Mill-Turn Spindle Speed: 16,000 RPM Fastest 5 axis Mill-Turn machine available on the market.
2022 FANUC ROBODRILL D21MIB5
Spindle Speed: 24,000 RPM
Travel: 19.68”X15.74”X12.9”
2022 FANUC ROBODRILL D21MIB5
Spindle Speed: 10,000 RPM
Travel: 19.68”X15.74”X12.9”
2022 FANUC ROBODRILL D21MIB5
Spindle Speed: 10,000 RPM
Travel: 19.68”X15.74”X12.9”
2022 FANUC ROBODRILL D21MIB5
Spindle Speed: 10,000 RPM
Travel: 19.68”X15.74”X12.9”
2018 MAZAK 510 C
Spindle Speed: 12,000 RPM
Travel: 40”X20”X24”
2017 MAZAK VERTICAL CENTER NEXUS 430A
Spindle Speed: 12,000 RPM
Travel: 22.05’’X16.93’’X19.45’’
2017 MAZAK VERTICAL CENTER NEXUS 430A
Spindle Speed: 12,000 RPM
Travel: 22.05’’X16.93’’X19.45’’
2018 FANUC ROBODRILL D21MIB5
Spindle Speed: 10,000 RPM
Travel: 19.68”X15.74”X12.9”
2018 FANUC ROBODRILL D21MIB5
Spindle Speed: 10,000 RPM
Travel: 19.68”X15.74”X12.9”
2015 HYUNDAI-WIA F500
Spindle Speed: 10,000 RPM
Travel: 40’’X20’’X28’’ travel.
2016 FANUC TWINHORN VH1010
Spindle Speed:8,000 Rpm
Travel: 40’’X20’’X124’’
2016 FANUC TWINHORN VH1010
Spindle Speed: 8,000 Rpm
Travel: 40’’X20’’X24’’
2014 FANUC TWINHORN VH1010
Spindle Speed: 8,000 RPM
Travel:40’’X20’’X24’’
2012 FANUC TWINHORN VA-500
Spindle Speed: 12,000 Rpm
Travel: 30’’X16’’X16’’
Inspection Equipment
2022 ZEISS SPECTRUM CMM
This machine is equipped with an RDS articulating and scanning head. Measuring volume is 500X500X600mm.
TESA MICRO-HITE 3D CMM
Measuring volume is 460X510X420mm.
MITUTOYO PH-3500 OPTICAL COMPARATOR
Travel range is 10’’X6’’.
2024 ZEISS SPECTRUM CMM
This machine is equipped with an RDS articulating and scanning head. Measuring volume is 500X500X600mm.
2024 ZEISS CONTURA CMM
OUR LARGEST VOLUME 900X1200X600mm.
This machine is equipped with an RDS articulating and scanning head. Measuring volume is 900X1200X600mm.
TESA HITE 700 X2 UNITS
28” measuring span with built in air cushion.
TESA HITE 400 x3 units
16” measuring span with built in air cushion.
KEYENCE TM-X5065
TELECENTRIC MEASUREMENT SYSTEM
MITITUYO SJ-210 PORTABLE SURFACE ROUGHNESS TESTER
2022 KEYENCE IM-8030 IMAGE DIMENSION MEASUREMENT SYSTEM
300 X 200mm field of view with built in light probe system.
